YTH ET/ES
YTH ET / ES
Trochoid pump 20 bar
with turbulence filter
Turbulenzfilter
Special turbulence automatically cleans the filter and prevents contamination.
20 bar
The ET/ES is an extremely efficient, self-priming trochoid pump.
Improved ET (=ES)
To improve our ET pump, the ES model was developed - especially suitable for hard and abrasive materials
Our YTH-ET / -ES is available in many variants
| type designation | engine type | Motor power (kW) | Feed quantity (L / min) | Maximaldruck (bar) | weight (kg) |
|---|---|---|---|---|---|
| YTH1500AE-T216EVD20B (L) | 400 V / 50 Hz | 1,5 | 24 | 20 | 35 |
| YTH1500AE-T216EVD20C (L) | 400 V / 50 Hz | 1,5 | 24 | 20 | 35 |
| YTH1500AE-S216EVD20B (L) | 400 V / 50 Hz | 1,5 | 24 | 20 | 35 |
| YTH1500A3-T216EVD20B (L) | 200V / 50 Hz | 1,5 | 24 | 20 | 39 |
| YTH1500A3-T216EVD20C (L) | 200V / 50 Hz | 1,5 | 24 | 20 | 39 |
| YTH1500A3-S216EVD20B (L) | 200V / 50 Hz | 1,5 | 24 | 20 | 39 |
type key
How to find out which YTH pump you need
TOP-YTH - EVD
Serviceliste
-
① Engine powerListenelement 11500: 1.5 kW
-
② Motor typeListenelement 2AE: 400V / 50 Hz A3: 200V / 50 Hz
-
③ flow rateListenelement 3T216: Gerotor / trochoid pump 16 cm³/rev S216: Gerotor / trochoid pump 16 cm³/rev
-
④ pressureListenelement 420: 20 bar
-
⑤ filtrationC: 20 m B: 50 m
-
⑥ Inline pump yes / noL: in-line pump (for external attachment) no identifier: submersible pump
