Piston pump 30 - 70 bar
with turbulence filter
Turbulenzfilter
Special turbulence automatically cleans the filter and prevents contamination.
30 - 70 bar
Piston movements transport the liquid at high to medium pressure.
EP-Solution
Thanks to a newly developed solution, we can optimize the use of our EP pump with the help of a bag filter
Our YTH-EP is available in many variants
| type designation | engine type | Motor power (kW) | Feed quantity (L / min) | Maximaldruck (bar) | weight (kg) |
|---|---|---|---|---|---|
| YTH2200AE-P010EVD*** | 400 V / 50 Hz | 2,2 | 15 | 70 | 53 |
| YTH2200AE-P016EVD*** | 400 V / 50 Hz | 2,2 | 24 | 35 | 62 |
| YTH2200AE-P016EVD*** | 400 V / 50 Hz | 2,2 | 24 | 30 | 62 |
| YTH3000AE-P016EVD*** | 400 V / 50 Hz | 3,0 | 24 | 70 | 62 |
| YTH2200A3-P010EVD*** | 200V / 50 Hz | 2,2 | 15 | 70 | 53 |
| YTH2200A3-P016EVD*** | 200V / 50 Hz | 2,2 | 24 | 35 | 57 |
| YTH3700A3-P016EVD*** | 200V / 50 Hz | 3,7 | 24 | 70 | 62 |
type key
How to find out which YTH pump you need
TOP-YTH - EVD
Serviceliste
-
① Engine powerListenelement 12200: 2.2 kW 3000: 3.0 kW 3700: 3.7 kW
-
② Motor typeListenelement 2AE: 400V / 50 Hz A3: 200V / 50 Hz
-
③ flow rateListenelement 3P010: Piston pump 10cm³ / rev. P016: Piston pump 16cm³ / rev
-
④ pressureListenelement 470: 70 bar 35: 35 bar
-
⑤ filtrationC: 20 m B: 50 m
-
⑥ Inline pump yes / noL: in-line pump (for external attachment) no identifier: submersible pump
