YTH CT
YTH CT
Trochoid pump 20 bar
with double cyclone filter
Double cyclonic filter
Two cyclone filters (one large and six small) remove chips from the coolant.
20 bar
The CT is an extremely efficient, self-priming trochoid pump.
Our YTH-CT is available in two variants
| type designation | engine type | Motor power (kW) | Feed quantity (L / min) | Maximaldruck (bar) | weight (kg) |
|---|---|---|---|---|---|
| TOP-YTH1500AE-T216CVD20 | 400 V / 50 Hz | 1,5 | 24 | 20 | 35 |
| TOP-YTH1500A3-T216CVD20 | 200 V / 50 Hz | 1,5 | 24 | 20 | 39 |
type key
How to find out which YTH pump you need
TOP-YTH - CVD
